RFID_LF Module

Description

A compact RFID module designed for low-frequency tag reading on Rugged Tablets, supporting HDX and FDX-B protocols. It features TTL serial communication and provides reliable reading ranges: up to 50 mm with ferrite antennas, approximately 6 cm with HDX transponders, and up to 10 cm with FDX-B transponders.

Specifications:

• Dimensions: 68.9 × 56 × 16.2 mm

• Weight: 38 g

• Input Voltage: DC 3.4V – 4.2V

• Communication Interface: TTL serial communication

• Operating Frequencies: 125 kHz and 134.2 kHz

• Supported Protocols: HDX, FDX-B

• Compliance Standards: ISO 11784, ISO 11785

• Compatible Tags: EM4100, 4102, 4200, EM4050, 4150, 4450, 4550, EM4305, FDX-B, EM4105, HITAG 1, HITAG 2, HITAG S, HDX
